DeepSeek Quad-RTX4090 GPU Computing Workstation (DeepSeek-G4S)

Server Configuration List and Detailed Introduction‌

1. ‌Processor (CPU)‌

• Model: Intel Xeon Gold 6148 (2 units)

• Cores/Threads: 20C/40T

• Frequency Range: 2.40GHz–3.70GHz

• Cache/Power: 27.50M/150W

2. ‌Chipset‌

• Model: Intel C621 Chipset

• Supported Features: Dual CPU sockets, LGA 3647 interface, 16 DIMM slots, 1 M.2 slot

3. ‌Memory (RAM)‌

• Standard Configuration: ECC DDR4 32G (expandable)

• Supported Specifications: ECC DDR4 16G/32G/64G/128G, up to 3TB total capacity

4. ‌Storage (HDD/SSD)‌

• Standard Configuration: 500GB Solid State Drive (SSD)

5. ‌Graphics Card (GPU)‌

• Standard Configuration:RTX 4090 * 2

• Supported Quantity: Up to 4 Turbo GPU cards

• Supported Models: RTX 4090/4080/3090/3080, A5000/A6000, etc.

6. ‌I/O Interfaces‌

• Network Ports: 2×X550 10GbE ports

• USB Ports: 2×USB 2.0, 4×USB 3.0

7. ‌Expansion Slots‌

• PCI-E 3.0 x16 Slots: 6

• PCI-E 3.0 x4 Slot (in x8 slot)

8. ‌Power Supply Unit (PSU)‌

• Power: 2000W

• Certification: 80PLUS Gold Certified

9. ‌Dimensions‌

• Depth×Width×Height: 650mm×436mm×177mm

‌Technical Highlights‌
This server configuration excels in high-performance computing scenarios such as big data analytics, scientific simulations, and AI-driven tasks.

• ‌CPU‌: Dual Xeon processors provide robust parallel computing capabilities.

• ‌Memory‌: Scalable DDR4 ECC memory ensures data integrity under heavy workloads.

• ‌Storage‌: SSD-based storage delivers rapid data access and low latency.

• ‌GPU‌: Multi-GPU support enables accelerated rendering and deep learning tasks.

• ‌Networking‌: Dual 10GbE ports facilitate high-speed data transfers.

‌Key Terminology Reference‌

• ‌ECC DDR4‌: Error-Correcting Code memory for enhanced reliability.

• ‌PCI-E 3.0‌: High-bandwidth interface for expansion cards.

• ‌LGA 3647‌: Socket type for Intel Xeon Scalable processors.

• ‌M.2 Slot‌: Interface for NVMe SSDs or Wi-Fi modules.
